Aeroboom Single Acting General Purpose Hydraulic Cylinder / Hydraulic Jack
Product Details:
- Color Yellow
- Product Type ASP Series Single Acting General Purpose Hydraulic Cylinder
- Usage Industrial
- Material Stainless Steel
- Structure ASP Series Single Acting General Purpose Hydraulic Cylinder
- Click to View more
Aeroboom Single Acting General Purpose Hydraulic Cylinder / Hydraulic Jack Price And Quantity
- 1 Number
- 45000 INR/Number
Aeroboom Single Acting General Purpose Hydraulic Cylinder / Hydraulic Jack Product Specifications
- Stainless Steel
- Yellow
- Industrial
- ASP Series Single Acting General Purpose Hydraulic Cylinder
- ASP Series Single Acting General Purpose Hydraulic Cylinder
Aeroboom Single Acting General Purpose Hydraulic Cylinder / Hydraulic Jack Trade Information
- 100 Number Per Week
- Week
- All India
Product Description
Features
- Multipurpose jacks.
- Gland Nut designed to withstand dead end load.
- Base mounting holes & collar threads are optional.
- Used in horizontal & vertical directions.
- Maintenance, fabrication, construction, Heavy industries, power & process plants, shipyards.
Specification
|
Model |
G Ram Internal thread |
H Thread depth (mm) |
J Collar threads |
K Length (mm) |
L PCDx No. of hole |
M Bottom thread size |
Thread depth (mm) |
|
ASPT-5 |
M16x2P |
15 |
M45x2P |
25 |
25x2 |
M6 |
12 |
|
ASPT-10 |
M22x2P |
17 |
M60x2P |
30 |
40x2 |
M8 |
12 |
|
ASPT-15 |
M22x2P |
20 |
M70x2P |
30 |
45x2 |
M8 |
12 |
|
ASPT-20 |
M24x2P |
25 |
M80x2P |
35 |
55x2 |
M8 |
12 |
|
ASPT-25 |
M24x2P |
25 |
M90x2P |
40 |
60x2 |
M6 |
16 |
|
ASPT-30 |
M30x2P |
25 |
M100x2P |
40 |
65x2 |
M10 |
16 |
|
ASPT-50 |
M42x2P |
25 |
M130x2P |
40 |
90x2 |
M10 |
16 |
|
ASPT-75 |
M48x2P |
25 |
M155x2P |
40 |
110x2 |
M10 |
16 |
|
ASPT-100 |
M48x2P |
25 |
M180x2P |
40 |
125x2 |
M12 |
16 |
|
ASPT-150 |
M82x2P |
25 |
M220x2P |
50 |
150x2 |
M16 |
18 |
|
ASPT-200 |
M90x2P |
25 |
M255x2P |
50 |
180x2 |
M16 |
22 |
|
Model |
Rated Capacity (ton) |
Capacity 700 bar (kN) |
Stroke (mm) |
Effective area (cm) |
Oil cap.(cc) |
A Closed height (mm) |
B Cylinder OD (mm) |
C Bore dia (mm) |
D Ram dia (mm) |
E Saddle dia (mm) |
Wt (Approx) (kg) |
|
ASP 100-50 |
100 |
1077 |
50 |
153.9 |
770 |
185 |
180 |
140 |
110 |
108 |
33 |
|
ASP 100-100 |
100 |
1077 |
100 |
153.9 |
1539 |
235 |
180 |
140 |
110 |
108 |
40.5 |
|
ASP 100-150 |
100 |
1077 |
150 |
153.9 |
2309 |
285 |
180 |
140 |
110 |
108 |
48 |
|
ASP 100-200 |
100 |
1077 |
200 |
153.9 |
3079 |
335 |
180 |
140 |
110 |
108 |
55.5 |
|
ASP 150-50 |
150 |
1589 |
50 |
227.0 |
1135 |
200 |
220 |
170 |
140 |
138 |
54 |
|
ASP 150-100 |
150 |
1589 |
100 |
227.0 |
2270 |
250 |
220 |
170 |
140 |
138 |
65.5 |
|
ASP 150-150 |
150 |
1589 |
150 |
227.0 |
3405 |
300 |
220 |
170 |
140 |
138 |
77 |
|
ASP 200-50 |
200 |
2199 |
50 |
314.2 |
1571 |
215 |
255 |
200 |
160 |
158 |
76 |
|
ASP 200-100 |
200 |
2199 |
100 |
314.2 |
3142 |
265 |
255 |
200 |
160 |
158 |
91 |
|
ASP 200-150 |
200 |
2199 |
150 |
314.2 |
4712 |
315 |
255 |
200 |
160 |
158 |
106.5 |
|
ASP 250-100 |
250 |
2661 |
100 |
380.1 |
3801 |
270 |
280 |
220 |
180 |
177 |
114 |
|
ASP 250-150 |
250 |
2661 |
150 |
380.1 |
5702 |
320 |
280 |
220 |
180 |
177 |
133 |
|
ASP 250-200 |
250 |
2661 |
200 |
380.1 |
7603 |
370 |
280 |
220 |
180 |
177 |
152 |
|
ASP 300-100 |
300 |
3167 |
100 |
452.4 |
4524 |
285 |
310 |
240 |
200 |
196 |
149 |
|
ASP 300-150 |
300 |
3167 |
150 |
452.4 |
6786 |
335 |
310 |
240 |
200 |
196 |
173 |
|
ASP 300-200 |
300 |
3167 |
200 |
452.4 |
9048 |
385 |
310 |
240 |
200 |
196 |
197 |
|
ASP 400-100 |
400 |
4008 |
100 |
572.6 |
5726 |
315 |
350 |
270 |
220 |
216 |
209 |
|
ASP 400-150 |
400 |
4008 |
150 |
572.6 |
8588 |
365 |
350 |
270 |
220 |
216 |
239 |
|
ASP 400-200 |
400 |
4008 |
200 |
572.6 |
11451 |
415 |
350 |
270 |
220 |
216 |
269 |
