ACLP Series Single Acting Pancake Lock Nut Cylinders
150000 INR/Number
Product Details:
- Product Type ACLP Series Single Acting Pancake Lock Nut Cylinders
- Color Black,Yellow
- Usage Industrial
- Material Aluminum
- Structure ACLP Series Single Acting Pancake Lock Nut Cylinders
- Power Hydraulic Watt (w)
- Click to View more
X
ACLP Series Single Acting Pancake Lock Nut Cylinders Price And Quantity
- 1 Number
- 150000 INR/Number
ACLP Series Single Acting Pancake Lock Nut Cylinders Product Specifications
- Hydraulic Watt (w)
- Industrial
- Aluminum
- ACLP Series Single Acting Pancake Lock Nut Cylinders
- ACLP Series Single Acting Pancake Lock Nut Cylinders
- Black,Yellow
ACLP Series Single Acting Pancake Lock Nut Cylinders Trade Information
- 100 Number Per Week
- 4-8 Week
- All India
Product Description
Features
- Low profile, flat design for use in confined spaces.
- Alloy Steel lock nut for mechanical load holding.
- Tilting saddle standard.
- Overflow port functions as a stroke limiter.
- Rugged, ACR 400 Female couplers with dust covers provided.
- Complies with ASME B30. 1 standards.
- Hardened chromed and threaded piston reduces wear and corrosion.
- High strength composite bearing provides support for off center loads without damaging the cylinder walls.
- High strength alloy steel body is precision machined to reduce wear and features a baked enamel finish for durability and corrosion protection.
Specification
| Model Number | Cyclinder Capacity | Stroke | Cyclinder Effective Area | Oil Capacity | Collapsed Height A | Extended Height B | Outside Diameter D | Cyclinder Bore Diameter E | Plunger Diameter F | Base to Advance Port H | Saddle Max.Tilt Angle R | Lock Nut Height S | |
| ton | (mm) | (cm2) | (cm3) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | | (mm) | (kg) | |
| ACLP-602 | 60 | 50 | 86,6 | 432 | 125 | 175 | 140 | 105,0 | Tr 104 x 4 | 19 | 5 | 28 | 15 |
| ACLP-1002 | 100 | 50 | 146,8 | 734 | 137 | 187 | 175 | 136,7 | Tr 136 x 6 | 21 | 5 | 31 | 26 |
| ACLP-1602 | 160 | 45 | 231,3 | 1040 | 148 | 193 | 220 | 171,6 | Tr 171 x 6 | 27 | 5 | 40 | 44 |
| ACLP-2002 | 200 | 45 | 285,6 | 1285 | 155 | 200 | 245 | 190,7 | Tr 190 x 6 | 30 | 5 | 43 | 57 |
| ACLP-2502 | 260 | 45 | 366,8 | 1650 | 159 | 204 | 275 | 216,1 | Tr 216 x 6 | 32 | 5 | 44 | 74 |
| ACLP-4002 | 400 | 45 | 559,5 | 2517 | 178 | 223 | 350 | 266,9 | Tr 266 x 6 | 39 | 4 | 55 | 134 |
| ACLP-5002 | 520 | 45 | 730,6 | 3287 | 192 | 237 | 400 | 305,0 | Tr 305 x 6 | 48 | 3 | 62 | 189 |
