Arch Series Single Acting Hollow Plunger Cylinders
Product Details:
- Color Yellow
- Product Type Arch Series Single Acting Hollow Plunger Cylinders
- Usage Industrial
- Material Aluminum
- Structure Other
- Click to View more
Arch Series Single Acting Hollow Plunger Cylinders Price And Quantity
- 25000 INR/Number
- 1 Number
Arch Series Single Acting Hollow Plunger Cylinders Product Specifications
- Other
- Aluminum
- Industrial
- Arch Series Single Acting Hollow Plunger Cylinders
- Yellow
Arch Series Single Acting Hollow Plunger Cylinders Trade Information
- 100 Number Per Week
- 4-8 Week
- All India
Product Description
FEATURES
- Hollow piston design allows for both pulling and pushing forces.
- Heavy-duty return spring provide quick retraction times.
- Collar threads for easy fixturing.
- Rugged, ACR-400 Female coupler with dust cover provided.
- Complies with ASME B30.1 standards.
- Hardened alloy steel guide ring eliminates over travel and provides support to reduce wear from off center loads.
- High strength composite bearing support for off center loads without damaging the cylinder walls.
- Hardened and chromed piston reduces wear and corrosion.
- Heavy-duty return spring provide quick retraction times.
- High strength alloy steel body is precision machined to reduce wear and features a baked enamel finish for durability and corrosion protection.
- Industrial U-cup style seal prevents costly leaks.
- Standard coupler provided with dust cover
Specification
| Model Number | Cyclinder Capacity | Stroke | Cyclinder EffectiveArea | Oil Cacpacity | Coll. Height A | Ext. Height B |
| ton | (mm) | (cm2) | (cm3) | (mm) | (mm) | |
| ARCH-120 | 13 | 8 | 17,9 | 14 | 55 | 63 |
| ARCH-121* | 42 | 17,9 | 75 | 120 | 162 | |
| ARCH-1211 | 42 | 17,9 | 75 | 120 | 162 | |
| ARCH-123 | 76 | 17,9 | 136 | 184 | 260 | |
| ARCH-202* | 20 | 49 | 30,7 | 150 | 162 | 211 |
| ARCH-206 | 155 | 30,7 | 476 | 306 | 461 | |
| ARCH-302* | 30 | 64 | 46,6 | 298 | 178 | 242 |
| ARCH-306 | 155 | 46,6 | 722 | 330 | 485 | |
| ARCH-603* | 60 | 76 | 82,3 | 626 | 247 | 323 |
| ARCH606 | 153 | 82,3 | 1259 | 323 | 476 | |
| ARCH-1003* | 100 | 76 | 133,0 | 1011 | 254 | 330 |
Base Mounting Hole Dimension (mm) | |||
Model Number | Bolt Circle U | Thread V | Thread Depth Z |
ARCH-120 | 50,8 | 5/16-18 UNC | 9,0 |
ARCH-121 | |||
ARCH-1211 | |||
ARCH-123 | 50,8 | 5/16-18 UNC | 12,7 |
ARCH-202 | 82,6 | 3/8-16 UNC | 9,4 |
ARCH-206 | 82,6 | 3/8-16 UNC | 9,4 |
ARCH-302 | 92,2 | 3/8-16 UNC | 14,0 |
ARCH-306 | 92,2 | 3/8-16 UNC | 14,0 |
ARCH-603 | 130,3 | 1/2-13 UNC | 14,0 |
ARCH-606 | 130,3 | 1/2-13 UNC | 14,0 |
ARCH-1003 | 177,8 | 5/8 -11 UNC | 19,0 |
| Saddle Type | Cylinder Model Number | Saddle Model Nr. | Saddle Dimension (mm) | ||
| A | B | C | |||
| Thread Hollow | ARCH-202,206 | HP-2015 | 53 | 1-8 | 9 |
| ARCH-302,306 | HP-3015 | 63 | 1 1/4-7 | 9 | |
| ARCH-603,606 | HP-5016 | 91 | 1 5/8 - 5 1/2 | 12 | |
| ARCH-1003 | HP-10016 | 126 | 2 1/2-8 | 13 | |
| Outside DIa. D | Cylinder Bore Dia E | Plunger Dia F | Cyl Base to Advance Port H | Saddle Dia. J | Saddle Protrusion From Plgr.K | Plunger Internal Thread O | Plunger Thread Length P | Collar Thread | Collar Thread Length | Centre hole Dia. | Weight | Model Number |
| mm | mm | mm | mm | mm | mm | | mm | | mm | mm | kg | |
| 69 | 54,1 | 35,1 | 9 | | | 3/4-16UN | 16 | 2 3/4-16 | 30 | 19,6 | 1,5 | ARCH-120 |
| 69 | 54,1 | 35,1 | 25 | | | | | 2 3/4-16 | 30 | 19,6 | 2,8 | ARCH-121 |
| 69 | 54,1 | 35,1 | 25 | | | 3/4-16UN | 16 | 2 3/4-16 | 30 | 19,6 | 2,8 | ARCH-1211 |
| 69 | 54,1 | 35,1 | 25 | | | 1 9/16-16UN | | 2 3/4-16 | 30 | 19,6 | 4,4 | ARCH-123 |
| 98 | 73,1 | 54,1 | 19 | 54 | 9,7 | 1 9/16-16UN | 19 | 3 7/8-12 | 38 | 26,9 | 7,7 | ARCH-202 |
| 98 | 73,1 | 54,1 | 25 | 54 | 9,7 | 1 9/16-16UN | 19 | 3 7/8-12 | 38 | 26,9 | 14,1 | ARCH-206 |
| 114 | 88,9 | 63,5 | 21 | 63 | 9,0 | 1 9/16-16UN | 22 | 4 1/2 -12 | 42 | 33,3 | 10,9 | ARCH-302 |
| 114 | 88,9 | 63,5 | 25 | 63 | 9,0 | 1 9/16-16UN | 22 | 4 1/2 -12 | 42 | 33,3 | 21,8 | ARCH-306 |
| 159 | 123,9 | 91,9 | 31 | 91 | 12,0 | 2 3/4-16UN | 19 | 6 1/4 - 12 | 48 | 53,8 | 28,1 | ARCH-603 |
| 159 | 123,9 | 91,9 | 31 | 91 | 12,0 | 2 3/4-16UN | 19 | 6 1/4 - 12 | 48 | 53,8 | 35,4 | ARCH-606 |
| 212 | 165,1 | 127,0 | 38 | 126 | 12,0 | 4-16 UN | 25 | 8 3/8-12 | 60 | 79,0 | 63,0 | ARCH-1003 |
