Alrc Series Double Acting High Tonnage Cylinder
Product Details:
- Usage Industrial
- Product Type Alrc Series Double Acting High Tonnage Cylinder
- Color Yellow
- Material Aluminum
- Structure Alrc Series Double Acting High Tonnage Cylinder
- Power Hydraulic Watt (w)
- Click to View more
Alrc Series Double Acting High Tonnage Cylinder Price And Quantity
- 100000 INR/Number
- 1 Number
Alrc Series Double Acting High Tonnage Cylinder Product Specifications
- Hydraulic Watt (w)
- Yellow
- Aluminum
- Alrc Series Double Acting High Tonnage Cylinder
- Industrial
- Alrc Series Double Acting High Tonnage Cylinder
Alrc Series Double Acting High Tonnage Cylinder Trade Information
- 100 Number Per Week
- 4-8 Week
- All India
Product Description
Features
- High strength alloy steel construction for increased durability.
- Hardened and chromed piston reduces wear corrosion.
- Built-in safety valve prevents accidental over pressurization.
- Base mounting holes enable easy fixturing.
- Easy to carry and position with included eye bolts.
- Environmentally friendly coating process provides a durable anti-corrosion finish.
- Optional tilt saddles available.
- Rugged, ACR-400 Female couplers with dust covers provided.
- Complies with ASME B30.1 standards.
Specification
| Base Mounting Hole 1) Dimensions (mm) | |||
| Model / Capacity ton | Bolt Circle U | Thread Size V | Min. Thread Depth Z |
| ALRG-50 | 65 | 2x M12 | 22 |
| ALRG-100 | 95 | 2x M12 | 22 |
| ALRG-150 | 130 | 2x M12 | 22 |
| ALRG-200 | 165 | 3x M12 | 22 |
| ALRG-250 | 190 | 3x M12 | 22 |
| ALRG-300 | 180 | 3x M16 | 30 |
| ALRG-400 | 205 | 3x M16 | 30 |
| ALRG-500 | 250 | 3x M24 | 36 |
| ALRG-600 | 275 | 3x M24 | 36 |
| ALRG-800 | 330 | 3x M24 | 36 |
| ALRG-1000 | 375 | 3x M24 | 36 |
| Model Number | Cylinder Capacity ton | Stroke mm | Cylinder Effective area mm | Oil Capacity cm2 | Collapsed Height A mm | Extended Height A mm | Outside Dia | Cylinder Bore dia E mm | Plunger Dia F mm | Base to Adv port H mm | Weigt Kg | Saddle Dia J1 mm | Saddle Height K1 mm | Saddle Model Number |
| ALRG-502 | 50 | 50 | 77,0 | 385 | 162 | 212 | 130 | 99,0 | 70,0 | 52 | 17 | 50 | 24 | ATG-50 |
| ALRG-504 | 100 | 77,0 | 770 | 212 | 312 | 130 | 99,0 | 70,0 | 52 | 20 | 50 | 24 | ATG-50 | |
| ALRG-506 | 150 | 77,0 | 1155 | 262 | 412 | 130 | 99,0 | 70,0 | 52 | 23 | 50 | 24 | ATG-50 | |
| ALRG-508 | 200 | 77,0 | 1540 | 312 | 512 | 130 | 99,0 | 70,0 | 52 | 27 | 50 | 24 | ATG-50 | |
| ALRG-5010 | 250 | 77,0 | 1924 | 362 | 612 | 130 | 99,0 | 70,0 | 52 | 31 | 50 | 24 | ATG-50 | |
| ALRG-5012 | 300 | 77,0 | 2309 | 412 | 712 | 130 | 99,0 | 70,0 | 52 | 34 | 50 | 24 | ATG-50 | |
| ALRG-1002 | 100 | 50 | 132,7 | 664 | 182 | 232 | 165 | 130,0 | 95,0 | 54 | 19 | 73 | 29 | ATG-100 |
| ALRG-1004 | 100 | 132,7 | 1327 | 232 | 332 | 165 | 130,0 | 95,0 | 54 | 29 | 73 | 29 | ATG-100 | |
| ALRG-1006 | 150 | 132,7 | 1991 | 282 | 432 | 165 | 130,0 | 95,0 | 54 | 40 | 73 | 29 | ATG-100 | |
| ALRG-1008 | 200 | 132,7 | 2655 | 332 | 532 | 165 | 130,0 | 95,0 | 54 | 50 | 73 | 29 | ATG-100 | |
| ALRG-10010 | 250 | 132,7 | 3318 | 382 | 632 | 165 | 130,0 | 95,0 | 54 | 61 | 73 | 29 | ATG-100 | |
| ALRG-10012 | 300 | 132,7 | 3982 | 432 | 732 | 165 | 130,0 | 95,0 | 54 | 71 | 73 | 29 | ATG-100 | |
| ALRG-1502 | 150 | 50 | 198,6 | 993 | 196 | 246 | 205 | 159,0 | 114,0 | 61 | 39 | 91 | 31 | ATG-150 |
| ALRG-1504 | 100 | 198,6 | 1986 | 246 | 346 | 205 | 159,0 | 114,0 | 61 | 52 | 91 | 31 | ATG-150 | |
| ALRG-1506 | 150 | 198,6 | 2978 | 296 | 446 | 205 | 159,0 | 114,0 | 61 | 65 | 91 | 31 | ATG-150 | |
| ALRG-1508 | 200 | 198,6 | 3971 | 346 | 546 | 205 | 159,0 | 114,0 | 61 | 78 | 91 | 31 | ATG-150 | |
| ALRG-15010 | 250 | 198,6 | 4964 | 396 | 646 | 205 | 159,0 | 114,0 | 61 | 92 | 91 | 31 | ATG-150 | |
| ALRG-15012 | 300 | 198,6 | 5957 | 446 | 746 | 205 | 159,0 | 114,0 | 61 | 105 | 91 | 31 | ATG-150 | |
| ALRG-2002 | 200 | 50 | 265,9 | 1330 | 216 | 266 | 235 | 184,0 | 133,0 | 67 | 55 | 118 | 35 | ATG-200 |
| ALRG-2006 | 150 | 265,9 | 3989 | 316 | 466 | 235 | 184,0 | 133,0 | 67 | 91 | 118 | 35 | ATG-200 | |
| ALRG-2008 | 200 | 265,9 | 5289 | 366 | 566 | 235 | 184,0 | 133,0 | 67 | 100 | 118 | 35 | ATG-200 | |
| ALRG-20012 | 300 | 265,9 | 7977 | 466 | 766 | 235 | 184,0 | 133,0 | 67 | 146 | 118 | 35 | ATG-200 | |
| ALRG-2502 | 250 | 50 | 366,4 | 1832 | 235 | 285 | 275 | 216,0 | 165,0 | 73 | 102 | 144 | 46 | ATG-250 |
| ALRG-2506 | 150 | 366,4 | 5497 | 335 | 485 | 275 | 216,0 | 165,0 | 73 | 136 | 144 | 46 | ATG-250 | |
| ALRG-25012 | 300 | 366,4 | 10993 | 485 | 785 | 275 | 216,0 | 165,0 | 73 | 207 | 144 | 46 | ATG-250 | |
| ALRG-3002 | 300 | 50 | 456,2 | 2281 | 312 | 362 | 310 | 241,0 | 197,0 | 101 | 184 | 160 | 62 | ATG-300 |
| ALRG-3006 | 150 | 456,2 | 6843 | 412 | 962 | 310 | 241,0 | 197,0 | 101 | 232 | 160 | 62 | ATG-300 | |
| ALRG-30012 | 300 | 456,2 | 13685 | 562 | 862 | 310 | 241,0 | 197,0 | 101 | 303 | 160 | 62 | ATG-300 | |
| ALRG-4002 | 400 | 50 | 559,9 | 2800 | 375 | 425 | 350 | 267,0 | 216,0 | 114 | 270 | 193 | 51 | ATG-400 |
| ALRG-4006 | 150 | 559,9 | 8399 | 475 | 625 | 350 | 267,0 | 216,0 | 114 | 330 | 193 | 51 | ATG-400 | |
| ALRG-40012 | 300 | 559,9 | 16797 | 625 | 925 | 350 | 267,0 | 216,0 | 114 | 421 | 193 | 51 | ATG-400 | |
| ALRG-5002 | 500 | 50 | 730,6 | 3653 | 419 | 469 | 400 | 305,0 | 248,0 | 114 | 401 | 228 | 63 | ATG-500 |
| ALRG-5006 | 150 | 730,6 | 10959 | 519 | 669 | 400 | 305,0 | 248,0 | 114 | 480 | 228 | 63 | ATG-500 | |
| ALRG-50012 | 300 | 730,6 | 21918 | 669 | 969 | 400 | 305,0 | 248,0 | 114 | 599 | 228 | 63 | ATG-500 | |
| ALRG-6002 | 600 | 50 | 855,3 | 4276 | 429 | 479 | 430 | 330,0 | 267,0 | 114 | 474 | 241 | 76 | ATG-600 |
| ALRG-6006 | 150 | 855,3 | 12829 | 529 | 679 | 430 | 330,0 | 267,0 | 114 | 565 | 241 | 76 | ATG-600 | |
| ALRG-60012 | 300 | 855,3 | 25659 | 679 | 979 | 430 | 330,0 | 267,0 | 114 | 701 | 241 | 76 | ATG-600 | |
| ALRG-8002 | 800 | 50 | 1176,3 | 5881 | 474 | 524 | 505 | 387,0 | 317,0 | 149 | 741 | 287 | 75 | ATG-800 |
| ALRG-8006 | 150 | 1176,3 | 17644 | 574 | 724 | 505 | 387,0 | 317,0 | 149 | 880 | 287 | 75 | ATG-800 | |
| ALRG-80012 | 300 | 1176,3 | 35288 | 724 | 1024 | 505 | 387,0 | 317,0 | 149 | 1058 | 287 | 75 | ATG-800 | |
| ALRG-10002 | 1000 | 50 | 1465,7 | 7329 | 564 | 614 | 560 | 432,0 | 343,0 | 174 | 1062 | 311 | 93 | ATG-1000 |
| ALRG-10006 | 150 | 1465,7 | 21986 | 664 | 814 | 560 | 432,0 | 343,0 | 174 | 1213 | 311 | 93 | ATG-1000 | |
| ALRG-100012 | 300 | 1465,7 | 43972 | 814 | 1114 | 560 | 432,0 | 343,0 | 174 | 1439 | 311 | 93 | ATG-1000 |
