AISL Series Intelligent Synchronous LIfting Hydraulic System
Product Details:
- Usage Industrial
- Product Type AISL Series Intelligent Synchronous LIfting Hydraulic System
- Color Yellow & Black
- Body Material Steel
- Type AISL Series Intelligent Synchronous LIfting Hydraulic System
- Force Power kilogram-force (kgf)
- Voltage 240 Volt (v)
- Click to View more
AISL Series Intelligent Synchronous LIfting Hydraulic System Price And Quantity
- 1000000 INR/Number
- 1 Number
AISL Series Intelligent Synchronous LIfting Hydraulic System Product Specifications
- Yellow & Black
- Steel
- Industrial
- AISL Series Intelligent Synchronous LIfting Hydraulic System
- 240 Volt (v)
- AISL Series Intelligent Synchronous LIfting Hydraulic System
- Power kilogram-force (kgf)
AISL Series Intelligent Synchronous LIfting Hydraulic System Trade Information
- 100 Number Per Week
- 4-8 Week
- All India
Product Description
Features
This system is hydraulic driven and automatically controlled by pressure and displacement closed loop to realize multi-point control. It can carry out synchronous lifting, synchronous landing, equal proportion synchronous lifting and other functions. The system uses frequency converter to control oil pump motor, and motor speed is changed by adjusting the frequency of power supply to achieve continuously adjusting oil pumps flow
Specification
| Model | Points | Synchronous Precision mm | Motor Power KW | Voltage AC/V | Working Pressure bar | Flow L/min | Oil Tank Capacity L | Dimensions （LXWXH） mm | Net Weight Kg |
| AISL-2A | 2 Points | <+/-0.2 | 1.1X2 | 380 | 700 | 1x2 | 130 | 760x820x1150 | 180 |
| AISL-2B | 2 Points | <+/-0.2 | 2.2X2 | 380 | 700 | 2x2 | 130 | 760x820x1150 | 240 |
| AISL-2C | 2 Points | <+/-0.2 | 5.5X2 | 380 | 700 | 4x2 | 250 | 960x880x1170 | 300 |
| AISL-4A | 4 Points | <+/-0.2 | 1.1X4 | 380 | 700 | 1x4 | 200 | 1100x875x1160 | 350 |
| AISL-4B | 4 Points | <+/-0.2 | 2.2x4 | 380 | 700 | 2x4 | 250 | 1200x820x1120 | 430 |
| AISL-4C | 4 Points | <+/-0.2 | 5.5X4 | 380 | 700 | 4x4 | 500 | 1100x960x1130 | 550 |
