Arac Series Single Acting Aluminum Cylinder
Product Details:
- Color Gray
- Product Type Arac Series Single Acting Aluminum Cylinder
- Usage Industrial
- Material Stainless Steel
- Structure Arac Series Single Acting Aluminum Cylinder
- Power Hydraulic Watt (w)
- Click to View more
Arac Series Single Acting Aluminum Cylinder Price And Quantity
- 35000 INR/Number
- 1 Number
Arac Series Single Acting Aluminum Cylinder Product Specifications
- Arac Series Single Acting Aluminum Cylinder
- Stainless Steel
- Hydraulic Watt (w)
- Gray
- Industrial
- Arac Series Single Acting Aluminum Cylinder
Arac Series Single Acting Aluminum Cylinder Trade Information
- 100 Number Per Week
- 4-8 Week
- All India
Product Description
Features
- Light weight, easy to carry.
- High strength aluminum alloy treated to resist wear and corrosion.
- Heavy-duty, straight pull return spring provide quick retraction times.
- Composite bearing prevents metal to metal contact.
- Rugged, ACR-400 Female coupler with dust cover provided.
- Complies with ASME B30.1 standards
| Optional Bolt on Tilt Saddle Dimension (mm) | |||
| For Cylinder model/Capacity ton | Tilt Saddle Model Number | Tilt Saddle Diameter J1 | Saddle Protrusion from Plunger K1 |
| ARAC-50 | CATG-50 | 50 | 24 |
| ARAC-100 | CATG-100 | 91 | 31 |
| ARAC-150 | CATG-200 | 118 | 35 |
Specification
| Model Number | Cyclinder Capacity 700 bar | Stroke | Cyclinder Effective Area | Oil Capacity | Collapsed Height A | Extended Height B | Outside Diameter D | Cyclinder Bore Diameter | Plunger Diameter F | Bottom to Advance Port | Weight |
| ton | (mm) | (cm ) | (cm ) | (mm) | (mm) | (mm) | E (mm) | (mm) | H (mm) | (kg) | |
| ARAC 202 | 20 | 50 | 31,2 | 156 | 174 | 224 | 85 | 63 | 50 | 27 | 3,6 |
| ARAC 204 | 100 | 31,2 | 312 | 224 | 324 | 85 | 63 | 50 | 27 | 4,1 | |
| ARAC 206 | 150 | 31,2 | 468 | 274 | 434 | 85 | 63 | 50 | 27 | 4,6 | |
| ARAC 208 | 200 | 31,2 | 634 | 324 | 534 | 85 | 63 | 50 | 27 | 5,1 | |
| ARAC 2010 | 250 | 31,2 | 780 | 374 | 624 | 85 | 63 | 50 | 27 | 5,6 | |
| ARAC 302 | 30 | 50 | 44,2 | 221 | 181 | 231 | 100 | 75 | 60 | 32 | 4,5 |
| ARAC304 | 100 | 44,2 | 442 | 231 | 331 | 100 | 75 | 60 | 32 | 5,2 | |
| ARAC 306 | 150 | 44,2 | 663 | 281 | 431 | 100 | 75 | 60 | 32 | 5,9 | |
| ARAC 308 | 200 | 44,2 | 884 | 331 | 531 | 100 | 75 | 60 | 32 | 6,6 | |
| ARAC3010 | 250 | 44,2 | 1105 | 381 | 631 | 100 | 75 | 60 | 32 | 7,3 | |
| ARAC 502 | 50 | 50 | 70,9 | 354 | 186 | 236 | 130 | 95 | 80 | 30 | 8,5 |
| ARAC504 | 100 | 70,9 | 709 | 236 | 336 | 130 | 95 | 80 | 30 | 9,8 | |
| ARAC 506 | 150 | 70,9 | 1063 | 286 | 436 | 130 | 95 | 80 | 30 | 11,1 | |
| ARAC508 | 200 | 70,9 | 1417 | 336 | 536 | 130 | 95 | 80 | 30 | 12,4 | |
| ARAC 5010 | 250 | 70,9 | 1771 | 386 | 636 | 130 | 95 | 80 | 30 | 13,7 | |
| ARAC 1002 | 100 | 50 | 143,1 | 715 | 221 | 272 | 180 | 135 | 110 | 46 | 17,3 |
| ARAC 1004 | 100 | 143,1 | 1431 | 271 | 371 | 180 | 135 | 110 | 46 | 19,6 | |
| ARAC 1006 | 150 | 143,1 | 2147 | 321 | 471 | 180 | 135 | 110 | 46 | 21,9 | |
| ARAC 1008 | 200 | 143,1 | 2863 | 371 | 571 | 180 | 135 | 110 | 46 | 24,2 | |
| ARAC 10010 | 250 | 143,1 | 3578 | 421 | 671 | 180 | 135 | 110 | 46 | 26,5 | |
| ARAC 1502 | 150 | 50 | 227,0 | 1135 | 243 | 293 | 230 | 170 | 140 | 51 | 25,3 |
| ARAC 1504 | 100 | 227,0 | 2270 | 293 | 393 | 230 | 170 | 140 | 51 | 29,3 | |
| ARAC 1506 | 150 | 227,0 | 3405 | 343 | 493 | 230 | 170 | 140 | 51 | 33,3 | |
| ARAC 1508 | 200 | 227,0 | 4540 | 393 | 593 | 230 | 170 | 140 | 51 | 37,3 | |
| ARAC 15010 | 250 | 227,0 | 5675 | 443 | 693 | 230 | 170 | 140 | 51 | 41,3 |
