Aeroboom Single Acting Low Height Cylinder ARSM ARCS Series
Product Details:
- Color Yellow & Black
- Usage Industrial
- Product Type ARSMARCS Series Single Acting Low Height Cylinder
- Material Stainless Steel
- Structure Flexible Cylinder
- Click to View more
Aeroboom Single Acting Low Height Cylinder ARSM ARCS Series Price And Quantity
- 1 Number
- 25000 INR/Number
Aeroboom Single Acting Low Height Cylinder ARSM ARCS Series Product Specifications
- Yellow & Black
- Stainless Steel
- Industrial
- ARSMARCS Series Single Acting Low Height Cylinder
- Flexible Cylinder
Aeroboom Single Acting Low Height Cylinder ARSM ARCS Series Trade Information
- 100 Number Per Week
- Week
- All India
Product Description
- Low profile, flat design for use in confined spaces.
- High strength alloy steel construction for increased durability.
- Hardened and chromed piston reduces wear and corrosion.
- Grooved piston end requires no saddle.
- Heavy duty, straight pull, return spring provides quick retraction time.
- Mounting holes permit easy fixturing.
- Environmentally friendly coating process provides a durable anti-corrosion finish.
- Rugged ACR-400 Female coupler with dust cover provided*.
- Complies with ASME B30.1 standards.
- Pressure Gauge Available to monitor system pressure See Gauges Page.
- High Pressure Hydraulic Hoses see Hoses Page.
|
Model |
Capacity |
Effective area |
Capacity |
|
|
km |
mm |
cm |
cm |
|
|
ARSM - 50 |
5 |
6 |
6,5 |
4 |
|
ARSM - 100 |
10 |
11 |
14,5 |
18 |
|
ARSM -200 |
20 |
11 |
28,7 |
32 |
|
ARSM - 300 |
30 |
13 |
42,1 |
55 |
|
ARSM - 500 |
50 |
16 |
62,1 |
99 |
|
ARSM - 750 |
75 |
16 |
102,6 |
164 |
|
ARSM - 1000 |
100 |
16 |
126,7 |
203 |
|
ARSM - 1500 |
150 |
16 |
198,1 |
317 |
|
ARSM -101 |
10 |
38 |
14,5 |
55 |
|
ARSM -201 |
20 |
45 |
28,7 |
129 |
|
ARSM - 302 |
30 |
62 |
42,1 |
261 |
|
ARSM -502 |
50 |
60 |
62,1 |
373 |
|
ARSM - 1002 |
100 |
57 |
126,7 |
722 |
|
Optional Bolt on Tilt Saddle Dimension (mm) |
||||
|
For Cylinder Model |
Model Number |
A |
B |
C |
|
ARCS-101 |
CAT-11 |
35 |
11 |
21 |
|
ARCS-201,302,502 |
CAT-51 |
50 |
15 |
29 |
|
ARCS-1002 |
CAT-101 |
71 |
17 |
35 |
|
RSM Cylinder Mounting Hole Dimension (mm) |
||||
|
Model Number |
Bolt Circle U1 |
Hole Dia V |
Counter Bore Dia. |
Counter Bore Depth |
|
ARSM-50 |
28,5 |
5,5 |
9,1 |
4,3 |
|
ARSM-100 |
36,6 |
7,1 |
10,7 |
7,9 |
|
ARSM-200 |
49,3 |
10,0 |
15,1 |
9,9 |
|
ARSM-300 |
52,3 |
10,0 |
15,9 |
11,2 |
|
ARSM-500 |
66,5 |
11,0 |
19,0 |
12,7 |
|
ARSM-750 |
76,2 |
13,5 |
20,6 |
14,2 |
|
ARSM-1000 |
76,2 |
13,5 |
20,6 |
14,2 |
|
ARSM-1500 |
117,3 |
13,5 |
20,6 |
14,2 |
|
Collapsed Height A |
Extended Height B |
Outside Diameter D |
Cylinder Bore Dia. |
Plunger Dia. |
Base to Advance Port H |
Plunger Protrusion From Base K |
Plunger to Base L |
Plunger to Mtg. Hole M |
Thread O |
DEpth P |
Bolt Circle U |
WEight |
Model Number |
|
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
Kg |
|
|
32 |
38 |
58x41 |
28,7 |
25,4 |
16 |
1 |
20 |
22 |
- |
- |
- |
1,0 |
ARSM50 |
|
43 |
54 |
82x55 |
42,9 |
38,1 |
19 |
1 |
27 |
34 |
- |
- |
- |
1,4 |
ARSM100 |
|
51 |
62 |
101x76 |
60,5 |
50,8 |
19 |
1 |
39 |
39 |
- |
- |
- |
3,1 |
ARSM200 |
|
58 |
71 |
117x95 |
73,2 |
63,4 |
19 |
2 |
47 |
44 |
- |
- |
- |
4,5 |
ARSM300 |
|
66 |
82 |
140x114 |
88,9 |
69,8 |
19 |
2 |
57 |
53 |
- |
- |
- |
6,8 |
ARSM500 |
|
79 |
95 |
165x139 |
114,3 |
82,6 |
19 |
2 |
69 |
66 |
- |
- |
- |
11,3 |
ARSM750 |
|
85 |
101 |
178x153 |
127,0 |
92,2 |
19 |
2 |
76 |
74 |
- |
- |
|
14,5 |
ARSM1000 |
|
100 |
116 |
215x190 |
158,8 |
114,3 |
23 |
2 |
95 |
82 |
- |
- |
- |
26,3 |
ARSM1500 |
|
88 |
126 |
69 |
42,9 |
38,1 |
17 |
5 |
- |
- |
M4 |
8 |
26 |
2,7 |
ARCS101 |
|
98 |
143 |
92 |
60,5 |
50,8 |
17 |
3 |
- |
- |
M5 |
8 |
40 |
5,0 |
ARCS201 |
|
117 |
179 |
101 |
73,2 |
66,5 |
19 |
3 |
- |
- |
M5 |
8 |
40 |
6,8 |
ARCS302 |
|
122 |
182 |
124 |
88,9 |
69,8 |
23 |
2 |
- |
- |
M5 |
8 |
40 |
10,0 |
ARCS502 |
|
141 |
198 |
165 |
127,0 |
92,2 |
31 |
1 |
- |
- |
M8 |
10 |
50 |
20,7 |
ARCS1002 |
